8.7 INTERCOM CONFIGURATION
One of the options on GSW2 PLUS unit is secure implementation of intercom support. Intercom
function is possible with the external audio module. Selecting (calling) apartment number is
achieved pressing the call button beside appropriate name plate.
This action will start a voice call procedure from Phone number 1 till Phone number 5. After the
call is answered the called user has the option to trigger the output by pressing “11” for opening
Output 1 or “21” for triggering Output 2.
If the call is answered the unit will stop dialing next numbers on the list.
Management of the intercom function is found under Intercom tab.
General settings:
Enable intercom button 1: User has to enable intercom button 1 before using it as a call
button 1.
Enable intercom button 2: User has to enable intercom button 2 before using it as a call
button 2.
Line open time: Defines maximum in-connection time in second before the unit will
automatically disconnect the call.
Figure 12: WEB Server-Intercom settings.
