GSW2 PLUS
USER MANUAL
Page 21
Output 2 - Settings for output 2:
 Output (relay) mode: User can select between 3 options
Disable-Output is disabled
Latching-Output is in latching mode. First Caller ID or PIN entry will activate the output,
second Caller ID or PIN entry will deactivate the output.
Time Pulse-Output is time pulse mode. After output is triggered it will be activated for the
time defined in Output pulse duration, after that time output will be restored.
 Output pulse duration: ON time for output in case of output mode Timer pulse.
 Output is: Output can work in normal or inverted (normally close) mode.
Normally open-In idle mode output pins are in open position.
Normally closed-In idle mode output connection are closed.
Additional output settings - Setting are used to link onboard actions with the outputs if needed:
 Unauthorized call or SMS received: If unauthorized call or SMS is received on the unit
this event will activate output defined under this section.
 Input 1 activate output: Activation of the input will activate output defined under this
section.
 Input 2 activate output: Activation of the input will activate output defined under this
section.
NOTE
Do to limitation of the outputs use additional outputs settings with care.
