8 DESCRIPTION OF TERMINAL BLOCKS
+BATT/Ground – Battery backup connector. In the original metal box it is possible to place a
1,2Ah/12V battery. Red fasten connector is for positive and black fasten connector is for negative
voltage battery supply.
+13,8V/Ground – Power Supply connector. On the left side is positive voltage (+ 12 VDC to
+15VDC) and the right site is GND voltage.
Input 1 – Alarm input 1. It can be N.O. (normal open) to GND or +12V DC, N.C. (normal close) to
GND or +12V DC.
Input 2 – Alarm input 2. It can be N.O. (normal open) to GND or +12V DC, N.C. (normal close) to
GND or +12V DC.
By default the Input 4 has “GSM NETWORK PRIORITY” function. When you trigger
the Input 4 (look the IN parameters) ZEUS4-MC LITE automatically switches to the
GSM network even if the PSTN line is still active. For the GSM priority function the
IN parameter must be 4, 5 or 6!
Output 1 – First diagnostic, remote control or alarm output. It is Open Collector output with
maximum loading current of 500mA.
Output 2 – Second diagnostic, remote control or alarm output. It is Open Collector output with
maximum loading current of 500mA.
Ta/Tb - Terminal blocks for user to connect his equipment (telephone, alarm panels…) to the
ZEUS4-MC LITE. In case that standard telephone line is connected to La/Lb block, than ZEUS4-
MC LITE just reroutes data from Ta/Tb to La/Lb. In case that standard line is not present on La/Lb
block, or GSM priority function is active, ZEUS4-MC LITE is used to transfer data (via GSM
module). The data path switch in case in standard line failure is done automatically.
La/Lb - Terminal blocks for standard telephone line connecting. It is possible to connect telephone
line from public telephone network (PSTN) or internal telephone line from office telephone
exchange (PABX).
