ZEUS4-MC Lite

INSTALLATION MANUAL

22 TECHNICAL SPECIFICATION

Description

Value

Power Supply

13,8 - 14,5V DC

Battery backup (optional)

12V/1,2Ah

Current consumption - peak

Current consumption - transmitting mode

250mA

Current consumption - idle mode

90mA

QUAD band GSM module

850/900/1800/1900 MHz

PCB dimensions

105 × 80 mm

Unit dimensions

118 × 170 × 60 mm

Unit dimensions - IP56 box

155 × 220 × 82 mm

Antenna SMA

Weight (without battery)

500g

Alarm inputs

GSM Priority input

Alarm outputs (open collector)

12V DC Power Supply input

Backup battery input

Telephone line interface

No. of alarm SMS per unit

Programmed telephone numbers

Anti-tamper protection

Event log buffer

1000
