20
Suspension Cable
The suspension cable (Figure 13) makes it possible for the sensor to be lowered into the water from
boats or bridges. To attach the sensor to the suspension cable, insert the mounting shaft on the sensor
mount into the hole at the back of the sensor. The thumbscrew needs to be seated in the groove on the
shaft, so make sure the shaft is completely inserted into the hole. Hand tighten the thumbscrew.
Figure 13. Suspension Cable
