Martin MAC 575 Krypton User Manual

MAC 575 Krypton DMX protocol 33
811
0
0 - 10
11
12 - 21
22
23 - 32
33
34 - 43
44
45 - 54
55
56 - 65
66
67 - 76
77
78 - 87
88
89 - 98
99
100 - 109
110 - 112
113 - 121
122 - 130
131 - 139
140 - 148
149 - 157
158 - 166
167 - 175
176 - 184
185 - 193
194 - 202
203 - 221
222 - 240
241 - 245
246 - 250
251 - 255
0
1 - 3
4
5 - 7
8
9 - 12
13
14 - 16
17
18 - 21
21
22 - 25
26
27 - 29
30
31 - 33
34
35 - 38
39
40 - 42
43
44 - 47
48 - 51
52 - 54
55 - 58
59 - 61
62 - 65
66 - 69
70 - 72
73 - 76
77 - 79
80 - 87
88 - 94
95 - 96
97 - 98
99 - 100
Gobo wheel 2 (static gobos): gobo selection, wheel scroll, random gobo
Continuous scroll
Open
Open → slot 1
Slot 1 (Inspiral)
Slot 1 → slot 2
Slot 2 (Spiral Drops)
Slot 2 → slot 3
Slot 3 (Radial Circles)
Slot 3 → slot 4
Slot 4 (“Les Mis” Whirlpool)
Slot 4 → slot 5
Slot 5 (Triangles)
Slot 5 → slot 6
Slot 6 (DNA)
Slot 6 → slot 7
Slot 7 (Radial Breakup)
Slot 7 → slot 8
Slot 8 (Warp Speed)
Slot 8 → slot 9
Slot 9 (Star Field)
Slot 9 → open
Open
Stepped scroll
Slot 9
Slot 8
Slot 7
Slot 6
Slot 5
Slot 4
Slot 3
Slot 2
Slot 1
Open
Continuous wheel rotation
CW, fast → slow
CCW, slow → fast
Random gobo
Fast
Medium
Slow
912
0 - 15
16 - 55
56 - 95
96 - 135
136 - 175
176 - 215
216 - 255
0 - 5
6 - 21
22 - 37
37 - 53
54 - 69
70 - 84
85 - 100
Macros
No macro
Static gobo wheel shake, slow → fast
Color wheel 1 shake, slow → fast
Color wheel 2 shake, slow → fast
Static gobo wheel and color wheel 1 shake, slow → fast
Static gobo wheel and color wheel 2 shake, slow → fast
Static gobo wheel and color wheels 1 and 2 shake, slow → fast
10 13
0 - 19
20 - 79
80 - 89
90 - 149
150 - 255
0 - 7
8 - 31
31 - 35
35 - 58
59 - 100
Prism
Prism off
Prism on, CCW rotation, fast → slow
Prism on, no rotation
Prism on, CW rotation, slow → fast
Prism off
11 14
0 - 199
200 - 215
216 - 229
230 - 243
244 - 246
247 - 249
250 - 252
253 - 255
0 - 77
78 - 84
85 - 89
90 - 94
95 - 96
97
98 - 99
100
Iris
Open → closed
Closed
Opening pulse, fast → slow
Closing pulse, fast → slow
Random opening pulse, fast
Random opening pulse, slow
Random closing pulse, fast
Random closing pulse, slow
16-bit
Basic
Mode
16-bit
Extended
Mode
DMX Value Percent Function
