Control menu 35
Control menu
Menu Item Options Notes (Default settings in bold print)
–
(16-bit basic)
–
(16-bit extended)
DMX address (new fixtures are supplied with address set to 1)
16-bit basic DMX mode with 2-channel (coarse and fine) control of
gobo rotation, pan, and tilt
16-bit extended DMX mode with basic mode features plus fine
control of dimmer, color wheels, iris, focus and zoom
Normal pan and tilt control
Map DMX pan control to tilt channel and vice versa
Normal pan control: left Æ right
Reverse DMX pan control: right Æ left
Normal tilt control: up Æ down
Reverse DMX tilt control, down Æ up
Normal pan/tilt speed
Optimize pan/tilt movement for speed
Optimize pan/tilt movement for smoothness
Normal effects speed
Optimize effects movement for speed
Optimize effects movement for smoothness
Pan/tilt speed slave: effects speed copies the pan/tilt speed set
via the control menu or via DMX
Optimize effects for speed
Optimize effects for silence (studio mode)
Display remains on
Display extinguishes 2 minutes after last key press
Display extinguishes 10 minutes after last key press
Display adjusts automatically for ambient light level
–
Adjust display intensity manually
Disable lamp off via DMX
Enable lamp off via DMX
Enable reset via DMX
Disable reset via DMX
Enable reset via DMX when reset command is held for 5 seconds
No automatic lamp strike
Lamp strikes automatically within 90 seconds of power on
Lamp strikes if DMX is present, douses after 15 mins. without DMX
Gobo and color wheels turn shortest distance (across open)
Gobo and color wheels do not cross open
Dimmer curve simulates tungsten incandescent bulb
characteristics
Near-linear dimmer curve
Disable color wheel blackout
Enable color wheel blackout
Disable iris blackout
Enable iris blackout
Return all settings (except calibrations) to factory defaults
, ,
Load custom configuration
Save current custom configuration
Table 2: Control menu
