Control menu 37
(cont.)
Prism off
Prism on, no rotation
–
Prism on: rotation CW and CCW; fast, medium and slow
Iris diameter: Press [Enter], then use up and down arrows to select
a value from 0 - 200
Iris closed
Fast opening pulse
Slow opening pulse
Fast closing pulse
Slow closing pulse
Fast random opening pulse
Slow random opening pulse
Fast random closing pulse
Slow random closing pulse
–
Focus position
–
Zoom position
–
Pan position
–
Pan position (fine)
–
Tilt position
–
Tilt position (fine)
Run a general test of all effects (for use by service technicians only)
To access
this menu,
hold [Enter]
pressed for
a few
seconds
Enable pan/tilt position correction system. See page 15
Disable pan/tilt feedback. Setting not saved
Enable position feedback from rotating effects. See page 15
Disable position feedback from rotating effects. Setting not saved
See “Adjustment submenu” on page 38
(OF = offset)
Pan calibration (adjustment range: 1 - 255)
Tilt calibration (adjustment range: 70 - 186)
Dimmer calibration (adjustment range: 90 - 170)
Color wheel 1 calibration (adjustment range: 103 - 153)
Color wheel 2 calibration (adjustment range: 103 - 153)
Gobo wheel 1 (rotating gobos) calibration (adjustment range: 103 -
153)
Gobo wheel 2 (static gobos) calibration (adjustment range: 103 -
153)
Focus calibration (adjustment range: 105 - 158)
Zoom calibration (adjustment range: 105 - 158)
Iris calibration (adjustment range: 128 - 255)
Prism calibration (adjustment range: 116 -140)
Set all effects to calibration value 128
PCB test: for service use only
Cooling fans: full speed
Cooling fans: temperature regulated
Manually set fixture to software update mode
Menu Item Options Notes (Default settings in bold print)
Table 2: Control menu
