FX wheel (wheel 3) static gobos and animation effect selection,
rotation, animation movement type
Continuous FX wheel scrolling
Open
Open → Gobo 1
Gobo 1
Gobo 1 → Gobo 2
Gobo 2
Gobo 2 → Gobo 3
Gobo 3
Gobo 3
→ Gobo 4
Gobo 4
Gobo 4 → Position 5
Position 5
Position 5 → Position 6
Position 6
Position 6 → Position 7
Position 7
Position 7 → Position 8
Position 8
Position 8 → Position 9
Position 9
Position 9 → Open
Open
Stepped FX wheel scrolling
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Position 5
Position 6
Position 7
Position 8
Position 9
Open
Continuous FX wheel rotation: set rotation speed on channel 15 (16-bit)
or 16 (16-bit extended)
CW FX wheel rotation, fast → slow
FX wheel stops at its current position
CCW FX wheel rotation, slow* → fast
No function
Animation movement functions: set speed on channel 15 (16-bit) or 16
(16-bit extended)
Smooth
Organic
Metronome
Run forwards, fast rewind
Run backwards, fast rewind
Random bounce
Interference
Random animation range position
Random gobo position
Random FX wheel position
Fade 0
15 16
0 - 10
11 - 255
0 - 4
4 - 100
FX wheel animation speed
Stop
Animation speed slow → fast
Fade 128
16 17
0 - 255 0 - 100
Frost
No frost → full frost
Fade 0
17 18
0 -10
11 - 138
139 - 255
0 - 4
4 - 54
54 - 100
Prism
Prism off
Prism indexing: set angle on ch. 18 (16-bit) or 19 (16-bit ext.)
Prism rotation: set direction and speed on ch. 18 (16-bit) or 19 (16-bit
ext.)
Snap 0
Basic
16-bit
Mode
16-bit
Extended
Mode DMX Value Percent Function
Fade
type
Default
value
Table 1: DMX Protocol
