36 MAC Viper Profile User Guide
* Adjustment should only be carried out by a qualified service technician with Martin™ service
documentation.
** High temperature warnings are canceled as soon as temperature returns to normal. If temperature
reaches cutoff level, the warning is replaced by a cutoff error message.
Error messages
Error messages indicate that there is a serious problem. The MAC Viper Profile communicates errors as
follows:
• Error messages flash in the display.
• If more than one error is detected, the fixture flashes all errors three times each.
• Errors are shown in the display regardless of display status: they override an inactive display and any
other information that the display might be showing.
• If an error is present, the status LED flashes red.
The possible error messages are listed in Table 4 below
:
SHNA
SHUTTER ADJUST
No shutter adjustment data in EEPROM. Shutter may be incorrectly adjusted*.
SL W
SAFETY LOOP
A safety loop error occurred but is no longer active. Warning message is cleared at the next
power off/on cycle.
TINA
TILT ADJUST
No tilt adjustment data in EEPROM. Tilt may be incorrectly adjusted*.
UITW
UI TEMP HIGH
Control panel PCB sensor detects that normal operating temperature is exceeded.**
ZFTW
ZF TEMP HIGH
Zoom/focus PCB sensor detects that normal operating temperature is exceeded.**
Short code
Long message and explanation
APER
AW POS ERROR
FX wheel position electrical indexing system timeout.
ARER
AW ROT ERROR
FX wheel rotation magnetic indexing system timeout.
BATC
BAL TEMP CUTOFF
Ballast temperature too high. Lamp is shut down, fans set to max. Error message cleared when
fixture is reset.
BEER
BEAM SHAPER POS
Prism position magnetic indexing system timeout.
BRER
BEAM SHAPER ROT
Prism rotation magnetic indexing system timeout.
BSER
BEAM SMOOTH ERR
Beam smoothing error.
C1ER
COLORWHEEL 1 ERR
Color wheel position magnetic indexing system timeout.
CDCM
CAL DATA CMY
Valid color mixing calibration data not detected in EEPROM. Fixture may be unable to read/write
color mixing calibration data to EEPROM.
CDEF
CAL DATA EFFECT
Valid effects calibration data not detected in EEPROM. Fixture may be unable to read/write
effects calibration data to EEPROM.
CDPT
CAL DATA P/T
Valid pan/tilt calibration data not detected in EEPROM. Fixture may be unable to read/write
pan/tilt calibration data to EEPROM.
Table 4: Error messages
Short code
Long message and explanation
Table 3: Warning messages
