Installation
Installation SQ2 with SAF3
Tab. 6: Installation opening
7. A conveyor belt support must be installed if the conveyor belt is
not adequately supported on the contact point between the
blade and the belt (see Section 6 under "Following
installation").
8. Repeat steps 1 to 6 on the opposite side of the chute wall.
WARNING RISK OF INJURY!
The secondary cleaner is heavy and can cause serious injuries if it
is dropped during lifting or moving.
Always use a suitable lifting device or engage the help of several
persons when lifting the secondary cleaner. Do not stand under
hanging loads.
Fig. 7:
*The cleaner should ideally be placed in the centre of the access port.
Item Description
A Blade-edge position
B Access port
