Martin SQC2 - Replacing a Single Blade

© Martin Engineering GmbH 41 M3682UK-09/17
Maintenance
6.3.2 Replacing a single blade
1. Remove the cleaner mainframe.
2. Loosen and remove the lower screw fittings for the specific
blade (1, Fig. 32).
3. Repeat step 2 for every additional blade to be replaced.
4. Remove the blade from the cleaner mainframe.
5. Attach a new blade to the cleaner mainframe.
6. Screw the blade to the cleaner mainframe.
7. Then install the cleaner again.
Fig. 32:
1
