Fig. 27:
0049-(0)6123-97820 www.martin-eng.de
Recommended values of tension for
MARTIN® SQC2™ secondary cleaner
®
For cleaners with shock ring:
Turn the nut of the threaded rod until all blades
make contact with the conveyor belt uniformly.
To tighten, turn it by another half to full revolution.
For cleaners with urethane shock ring:
Turn the nut of the threaded rod until all blades
make contact with the conveyor belt uniformly.
To tighten, turn another 2 full revolutions.
Teilenr.: SQC2-10002UK
No. 23395
! WARNING
Body parts and/or clothing may get caught and pulled in by rotating parts
or by the moving conveyor belt. Before any installation or maintenance work
is carried out, ensure that all power sources to the conveyor belt system and its
accessories are switched off and secured against inadvertent reactivation.
Use warning signs!
