© Martin Engineering GmbH 20 M3682UK-09/17
Installation
5.2.3 Installing the cleaner
1. Remove the retaining pin from the blade cartridge.
2. Remove the blade cartridge.
NOTE
The following steps 1 and 2 are only intended to make installation
easier and can be used for the SQC2 cleaner.
With cleaners having part number 41605, insert the cleaner
mainframe into the tensioner as described in step 3.
Fig. 12:
Fig. 13:
