Martin SQC2 - Attaching the Secondary Cleaner

© Martin Engineering GmbH 29 M3682UK-09/17
Installation
5.2.7 Attaching the secondary cleaner
If all of the dimensions are correct and the secondary cleaner
aligned, then it can be attached on both sides by the hexagon head
screw (16, Fig. 23) and the square head screw (18, Fig. 23) of the
clamp (3, Fig.23). Otherwise, it must be reinstalled or repositioned.
Fig. 23:
16
18
3
