Preparing for the installation

3. The delivery should include the following parts, depending on

the scope of the order:

•Martin

SQC2™ Secondary Cleaner

•Two Martin

SQC2™ tensioners

• Two Crushing Hazard Warning Labels

Part No. 30528

• Two Conveyor Products Warning Labels:

Part no. 23395

• Two label for tension values:

Part No. SQC2-10002G

• Installation instructions.

4. Report any missing or damaged parts to Martin Engineering or

one of its authorised dealers.

4.1.3 Removal of the tensioner

The Martin

QC™ #2 tensioners must first be removed to prepare

for the installation. The following steps must be taken for both spring

tensioners.

1. Pull the wire lock pin (7, Fig.1) out of the upper bearing bush

(5, Fig.1).

Fig. 1:
