Martin SQC2 - SQC2 Cleaner with Aluminium Cartridge Parts

© Martin Engineering GmbH 47 M3682UK-09/17
Part numbers
9.4 Inspection doors
9.5 Installation manuals
9.6 Various parts
Description Part No.
Door with rubber cover 229 x 305 mm CYAR-0912
Steel door 229 x 305 mm CYA-0912
Door with rubber cover 305 x 356 mm CYAR-1214
Steel door 305 x 356 mm CYA-1214
Door with rubber cover 305 x 457 mm CYAR-1218
Steel door 305 x 457 mm CYA-1218
Door with rubber cover 457 x 610 mm CYAR-1824
Steel door 457 x 610 mm CYA-1824
Door with rubber cover 610 x 610 mm CYAR-2424
Steel door 610 x 610 mm CYA-2424
Description Document
Inspection doors M3127
Description Part No.
Hanger mount (pair):
For installing the MARTIN
®
SQC2™ tensioner on
the belt framework instead of a chute wall.
34233-E
Bracket for counter-roller:
For belt support above the secondary cleaner
The first XX specifies the belt width in inches; the
third X the roller type; while the final X is the roll
diameter in inches:
32290-XXXX
>>> Conveying direction >>>
