Martin SQC2 - Replacing a Single Blade

© Martin Engineering GmbH 39 M3682UK-09/17
Maintenance
4. Loosen the square head screw (18, Fig.26) and the hex head
screw (16, Fig.26) of the clamp (3, Fig.26) on the operator side.
5. Remove the locking bolt from the cleaner mainframe.
Fig. 29:
Fig. 30:
16
18
3
