Dismantling: Removing the top caps
Put the fork in the vice in vertical position, fixing it by the dropouts.
Dismantling: Removing the top right cap
Remove the protection cap (1).
Using a small pin screwdriver, blow the air off the fork leg, pushing on the air valve.
Fully unscrew lock cap (2) with a 21mm socket spanner.
Remove lock cap (2).
Dismantling: Removing the top left cap
With a 2mm Allen wrench loosen screw (4).
Remove first the screw (4), then the ETA control knob (5).
Fully unscrew lock cap (2) using a 21mm socket spanner.
Lift out lock cap (2).
© Marzocchi Suspension
2005 - MX Comp ETA
