Marzocchi MX Comp ETA 2005 - Dismantling the ETA Cartridge

Remove bushing (4), valve (5) and three-point ring (6) from the pumping element.
Remove the preload tube (9) ( only for models with 105mm travel ).
Remove the rebound spring (7).
If the piston segment (8) is damaged, you can prize it off with a small flat-tip screwdriver.
Dismantling: Dismantling the ETA cartridge
Loosen and remove nut (1) with a 10mm fixed spanner.
Be very careful during this operation, as the preloaded spring (2) could eject with violence
the parts located on the top [nut (1), washer (3) and preload tube (7)].To avoid dangerous
situations, slightly preload the spring pressing down washer (3) so that it can counteract the
action of the spring. Also avoid to direct the fork assembly side towards people or animals.
Remove washer (3), the preload tube (7) and spring (2).
