Marzocchi MX Comp ETA 2005 - Dismantling Right Pumping Element and Valve

Pull the crown-stanchion unit (3) off the arch-slider assembly (4).
Dismantling: Dismantling the right pumping element and valve
Remove the bottom pad (1).
Using the special round-nose pliers, remove stop ring (2).
Pull out the pumping element (3) complete with rebound spring and valve.
