Masimo NomoLine ISA AX+ User Manual

NomoLine ISA Service Manual Chapter 1: Description
www.masimo.com 15 Masimo
Additional Equipment Required
The following components are not supplied by Masimo with the maintenance kit, and must
be purchased separately to perform the maintenance procedures:
Name Description Example
Manufacturer/PN*
Calibration Gas
Regulator Kit
Gas regulator kit includes:
• Manometer with pressure indicator,
needle valve and rotameter
• ET tube with blue 15 mm male connector
• Luer lock plug
Note: The thread of the manometer is UNEF
7/16"-28 and it will fit GE Healthcare’s
calibration gas cylinder REF 755580/755583
and Philips M1662A
Masimo/900910
Calibration gas
cylinder for
NomoLine ISA CO
2
.
Calibration gas cylinder from GE Healthcare
(5% CO
2
bal air)
GE
Healthcare/755580
Calibration gas
cylinder for ISA
AX+/OR+
Calibration gas cylinder from GE Healthcare
(5% CO
2
, 2% DES, 33% N
2
O, 55% O
2
bal N
2
)
GE
Healthcare/755583
Calibration gas
cylinder for ISA
AX+/OR+
Calibration gas cylinder from Philips (5% CO
2
,
2% DES, 43% N
2
O, 50% O
2
)
Philips/M1662A
Manual Pressure
Gauge Meter
Welch Allyn DS-55 Welch
Allyn/DS55-300
Handheld Digital
Manometer
HM28 Handheld digital manometer** Huber Instrumente
AG/HM28
* Or equivalent.
** Accuracy specification: 0-500 mbar 0.1% FS
