Replacing the Power Fuse
specified measurement range.
DC/AC(TRMS) Voltage
The Meter is capable of measuring voltage up to 1000 V DC and 750 V AC.
To perform a voltage measurement:
1. Turn rotary switch to position
，
LCD panel displays‘DC’; press FUNC button when measuring AC voltage,
and LCD display ‘AC’;
2. Connect red test lead with VΩHz terminal and black test lead with COM terminal;
3. Connect test leads to test circuit;
4. The Meter selects the appropriate range in the autorange mode. The function and measurement are displayed;
5. By pressing the RANGE button, it is possible to select range manually. While displaying OL during manual range
measurement, it is necessary to select a larger range. When OL displaying under the maximum range, it indicates
the voltage exceeding 1000V,so it is necessary to remove both the red and black test leads from the measured
circuit immediately.
Note: In case of probe hanging in the air, the voltage inducted by the testing line may cause unstable readings on the
display screen, but that will not affect the accuracy of measurement.
