BENCH MODEL MULTIMETER
DCmV/ACmV
The Meter is capable of measuring mV up to 220mV.
To perform a mV measurement:
1. Turn rotary switch to position
，
LCD panel displays‘DC’; press FUNC button when measuring AC mV,
and LCD display ‘AC’;
2. Connect red test lead with VΩHz terminal and black test lead with COM terminal;
3. Connect test leads to test circuit;
4. The function and measurement are displayed;
5. While displaying OL during measurement, it is necessary to remove both the red and black test leads from the
