Replacing the Power Fuse
Replacing the Battery
When the multimeter displays the “ ” mark, the battery must be replaced to maintain proper operation. Use the following
procedure to replace the battery:
Disconnect test leads from any live source, turn the rotary switch to off, and remove the test leads from the input
terminals.
Remove screws on the battery cover and open the case.
Remove the exhausted battery and replace with a new equivalent 9 voltge battery.
Two types of batteries are used in the bench multimeter: one of is a NEDA 1604 6F22 006P type one piece or equivalent 9
voltge battery; other of is IEC LR6 AM3 AA 1.5V×6 pieces.
Never use the bench multimeter unless the battery cover is in place and fastened fully.
Note: To avoid electrical shock, disconnect power leads from live power sourceand remove the test leads and any input
signals before replacing the battery. Replace only with same type of battery.
Chapter 6 Accessories
Item Quantity
Manual 1
Test Leads 2
Power Cord
1
