Replacing the Power Fuse
DC mA / AC mA measurement
The Meter is capable of measuring current from 1μA
～
220mA
To perform the measurement:
1. Turn rotary switch to position
，
LCD panel displays‘DC’; press FUNC button when measuring AC
Current, and LCD display ‘AC’;
2. Connect red test lead with μA/m A terminal and black test lead with COM terminal;
3. Turn off the power of the measured circuit, connect the red and black probes to the measured circuit in serial way
and then turn on the power of the measured circuit;
4. The Meter selects the appropriate range in the autorange mode. The function and measurement are displayed;
