Replacing the Power Fuse
Clamp Measurement
The Meter is capable of measuring current up to 2200A
To perform the measurement:
1. Turn rotary switch to position
，
LCD panel displays‘DC’; press FUNC button when measuring AC Current,
and LCD display ‘AC’;
2. Connect red test lead with VΩHz terminal and black test lead with COM terminal;
3. Connect test leads to clamp adapter’s output terminal ;
4. The Meter selects the appropriate range in the autorange mode. The function and measurement are displayed;
5. By pressing the RANGE button it is possible to select range manually. While displaying OL during manual range
measurement, it is necessary to select a larger range. When OL displaying under the maximum range, it indicates
the voltage exceeding 2200A,so it is necessary to remove both the red and black test leads from the adapter output
