Mastech MS8040 - Logic Frequency; Linear Frequency

BENCH MODEL MULTIMETER
AC Voltage Accuracy
Range Resoluti
on
Accuracy
40Hz~60Hz 60Hz—5KHz 5KHz—10KHz
200mV 0.01mV ±(0.5% +30) ±(1.5% +30) ±(2.5% +30)
2V 0.1mV ±(0.5% +30) ±(1.5% +30) ±(2.5% +30)
20V 1mV ±(0.5% +30) ±(1.5% +30) ±(2.5% +30)
200V 10mV ±(0.5% +30) ±(1.5% +30) ±(2.5% +30)
750V 0.1V ±(0.5% +30) ±(1.5% +30)
（
1KHz
）
Unspecified
Note: Above accuracies can be guaranteed within 20% - 100% of the full range .
DC Voltage Accuracy
Range Resolution Accuracy
200mV 0.01mV ±(0.05% +6)
2V 0.1mV ±(0.05% +6)
20V 1mV ±(0.05% +6)
200V 10mV ±(0.05% +6)
1000V 0.1V ±(0.05% +6)
Note: Above accuracies can be guaranteed within the full range.
AC Current Accuracy
Range Resolutio Accuracy
