Mastervolt PowerCombi 12V/1200W-50A 120V

26
PowerCombi Inverter/Charger
PowerCombi
12V/1200W-50A
PowerCombi
12V/2000W-100A
Battery Temp. compensation
14mV per °F [-25 mV per °C]
(if battery temperature sensor is applied)
Battery Control (3-stage Battery
Chargers); DIP switch adjustable
Stage
Battery type
Flooded
(default)
GEL
AGM
Custom
Bulk
14.40V
14.40V
14.40V
14.40V*
Absorption
14.25V
14.25V
14.25V
14.25V*
Float
13.25V
13.80V
13.80V
13.25V*
* Adjustable by PowerCombi Remote Control Panel or PowerCombi Interface
Auxiliary Output Voltage
Same as charge voltage
Auxiliary Output Current
20A Max
20A Max
Transfer system specification
AC Input protection
30A Max (resettable breaker)
General Specification
Dimensions hxwxd in mm [inches]
251x116x386
[9.88x4.57x15.20]
251x116x453
[9.88x4.57x17.83]
Weight in kg [lb]
4.5 [10]
6 [13]
Protection degree
IP 21
Operating temperature
(see Figure 10)
-4°F to 140°F, derating > 104°F
[-20°C to 60°C, derating > 40°C]
Relative humidity
Max 93%, Non-condensing
Cooling
Fan
Power sharing function
Yes (see section 3.4)
Mains support mode
Yes (see section 3.4)
Safety standard
UL458 incl. Supplement SA, UL1741, ABYC A-31
EMC Standards
Certified FCC Class A
Options
Remote control
Dry contacts
Remote Control Panel
Product code 77010700
Dry Contact Terminal
By a relay (max 1A)
MasterBus compatible
Via PowerCombi Interface (product code 77032900)
Specifications are subject to change without prior notice.
