Mastervolt PowerCombi 12V/1200W-50A 120V

PowerCombi Inverter/Charger
25
8 TECHNICAL DATA
8.1 Specifications
PowerCombi
12V/1200W-50A
PowerCombi
12V/2000W-100A
Product code
36211200
36212000
Specification Inverter
Nom. battery voltage
12 VDC
Input voltage Range
10.5-16.5 VDC
Input Over-Voltage Protection
15.5 VDC (1 sec. delay)
Input Over-Voltage Recovery
15.0 VDC (5 sec. delay)
Input Under-Voltage Protection
10.0 VDC (3 sec. delay)
Input Under-Voltage Recovery
11.5 VDC (5 sec. delay)
Input Current (Max)
132 A
DC
260A
DC
No Load Current
<3.0A@12.5V
<4.0A@12.5V
Standby Current
<0.4A
Cont. power at 77°F [25°C],
cos phi 1
1200 W
2000 W
Peak load
101%-115% (1 min)
101%-115% (1 min)
2400 W (2s)
4000 W (2s)
Output voltage
100/110/115/120 VAC (± 3%) –
50/60 Hz (± 0,3 Hz)
Max. Efficiency (Full Load)
89%
Output waveform
Pure Sine Wave (THD<5% @ 12.5V/115VAC, linear load)
INV. AC output
12A Max
20A Max
AC Output max total
30A Max
30A Max
Input Protections
Over / Under voltage
AC Output Protection
Over load, Short circuit
Temperature Protection
Yes
Battery Temp. Protection
Through temperature sensor (product code 41500700)
Technology
High frequency
Specification Charger
Nominal Input
110 VAC, 50/60Hz (± 3 Hz), user-selectable
Input Voltage range
90-132 VAC
Nominal AC input current
8.2A (@110VAC)
16.5A (@110VAC)
Max. Efficiency
>88%
Power Factor
>0.95
Max. Charging Current
50A
100A
