OVERVIEW
2 August 2010 / SunMaster CS15TL/CS20TL / EN
OVERVIEW CS15TL / CS20TL
Figure 1: Inside view of the CS15TL/CS20TL
1. 3-phase 400V output plug
2. Fan module
3. Communication module
4. External grounding (PE) facility
5. Multi-language display
6. DC input 1
7. DC input 2
8. Foot stands
9. Air outlets
