SPECIFICATIONS
26 August 2010 / SunMaster CS15TL/CS20TL / EN
CS15TL CS20TL
SAFETY DEVICES
Island protection Redundant voltage and frequency window
monitoring compatible with national standards
Redundant voltage and frequency window
monitoring compatible with national
standards
Safety devices DC side • isolation resistance measurement
• polarity protection (diodes)
• surge protection class III (varistors)
• overload (temperature controlled power
derating)
• isolation resistance measurement
• polarity protection (diodes)
• surge protection class III (varistors)
• overload (temperature controlled power
derating)
Safety devices AC side • voltage / frequency window
• independent AC relays
• Integrated RCD (DC sensitive)
• DC current injection protection
• Ceramic fuse
• Class III surge protection
• voltage / frequency window
• independent AC relays
• Integrated RCD (DC sensitive)
• DC current injection protection
• Ceramic fuse
• Class III surge protection
SYSTEM INFORMATION
User interface Multi-language black-on-white graphical LCD
display. Languages: English, Nederlands,
Deutsch, Français, Castellano, Italiano
Multi-language black-on-white graphical LCD
display. Languages: English, Nederlands,
Deutsch, Français, Castellano, Italiano
Diagnostics • 365 days datalogger and real time clock
• 10 years diagnostic memory
• 365 days Datalogger and real time clock
• 10 years diagnostic memory
External communication A: MasterBus stringbox and transformer
interface with two connectors
B: MasterBus field service interface with two
connectors
C: 2 RS485 connections for DataControl
Professional, maximum 20 inverters, 1000 m
maximum cable length
A: MasterBus stringbox interface with two
connectors
B: MasterBus field service interface with two
connectors
C: 2 RS485 connections for DataControl
Professional, maximum 20 inverters, 1000 m
maximum cable length
MasterBus powering Yes, when AC and/or DC is available Yes, when AC and/or DC is available
MasterBus menu languages English, Nederlands, Deutsch, Français,
Castellano, Italiano, Norsk, Svenska, Suomi,
Dansk *
English, Nederlands, Deutsch, Français,
Castellano, Italiano, Norsk, Svenska, Suomi,
Dansk *
MISCELLANEOUS
Cooling User replaceable fan bracket User replaceable fan bracket
Enclosure Aluminium with powder coating.
Rubber foot stands are part of the enclosure.
Mounting bracket.
Aluminium with powder coating.
Rubber foot stands are part of the enclosure.
Mounting bracket.
String box option IP65 enclosure;
Integrated DC load switch 2x1000V DC /30A;
Integrated string fuses;
Integrated string current monitoring via
Masterbus connection to inverter;
12 (2 x 6) string connections with MC 4 mm
type connectors or glands.
IP65 enclosure;
Integrated DC load switch 2x1000V DC /30A;
Integrated string fuses;
Integrated string current monitoring via
Masterbus connection to inverter;
12 (2 x 6) string connections with MC 4 mm
type connectors or glands.
Transformer option 20kW 3-phase transformer in IP54 enclosure
Cooling: natural convection
Transformation losses : max 2%
Weight 200 Kg.
20kW 3-phase transformer in IP54 enclosure
Cooling: natural convection
Transformation losses : max 2%
Weight 200 Kg.
* The number of menu languages may change without prior notice.
