24
10.1.3 How to set up the “WIFI” function - continued
3. Install WiFi config software for WiFi connection - continued
Step 6: Press the stop key on the number keypad to back. Use the quick key Speed UP and Speed DOWN LEVEL keys to select "Import
Setting" (Figure G).
Step 7: Press the pause key to start wifi installation process (Figure H).
Step 8: When the message shows “Success !!" in a short time, it means the update is complete (Figure I).
4. Console WiFi function test
Step 1: Enter Manager mode -> Internet -> MAC ID (Figure A).
Step 2: If WiFi Module was installed correctly, the screen will show the MAC ID data (Figure B).
FIGURE HFIGURE G
FIGURE I
FIGURE BFIGURE A
CHAPTER 10: SPECIFICATIONS AND ASSEMBLY GUIDE
10.1 WIFI INSTALLATION - CONTINUED
