28
CHAPTER 7: SERVICE MODE
7.2 SERVICE MODE - TAB 1
T7X-02
Keypad
T7X-03 Keypad
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Machine Type Treadmill This option allows the user to select the current model. N/A
Serial Number This option displays the serial number of the console and frame. N/A
Show Boot Factory setting only. N/A
Keypad This option allows the user to select the keypad type (see above).
Accumulated Distance This option displays the total distance. Displayed in native units (miles or kilometers). N/A
Accumulated Time This option displays the total time. N/A
Storaged Data This option allows a user to export or import data to the unit via a USB drive.
SERVICE MODE
Setup
To Next Page
