Matrox Display Wall – User Guide 35
Connecting your Mura MPX Series card
This section describes how to connect your Matrox Mura MPX Series card.
Once all your cards are connected, restart your system and install your Matrox software (see
“Installing your software”, page 50).
Supported hardware More information
Input/Output
Mura MPX-4/4, MPX-4/2 See page 36.
Mura MPX-SDI See page 38.
Input
Mura IPX Series (capture cards) See page 32.
Mura MPX-V16 , MPX-V8 See page 42.
Output Mura MPX-4/0 See page 40.
Console
P690 PCIe ×16 See page 71.
P690 Plus LP PCIe ×16
(dual-monitor cable)
See page 72.
P690 Plus LP PCIe ×16
(quad-monitor cable)
See page 74.
