Matrox Display Wall – User Guide 79
Description of supported connections
Matrox M9138 LP PCIe ×16 and M9148 LP PCIe ×16
Device connector Description
DisplayPort If your monitor has a DisplayPort connector, attach your monitor
cable to the DisplayPort connector on your Matrox card. Connect the
other end of the cable to your monitor.
DVI If your monitor has a DVI connector, use a DisplayPort to DVI adapter
(active
*
) to connect your monitor cable to the DisplayPort connector
on your Matrox card. Connect the other end of the cable to your
monitor.
* Only active adapters (sold separately) are supported. Passive adapters aren’t supported.
HDMI If your monitor has an HDMI connector, use a mini DisplayPort to
HDMI adapter (active
*
) to connect to the mini DisplayPort connector
on your Matrox card. Connect your monitor to the HDMI connector
on your adapter.
WA R N I NG : To avoid damaging the
DisplayPort connector on your DisplayPort
monitor cable or on your graphics
hardware, carefully remove the DisplayPort
cable by pressing the latch on the top of the
DisplayPort connector while removing the
connector.
