80 Matrox Display Wall – User Guide
Connection overview
Description of supported connections
Device connector Description
DisplayPort If your monitor has a DisplayPort connector, attach your mini
DisplayPort to DisplayPort cable to your Matrox card. Connect the
other end of the cable to your monitor.
DVI If your monitor has a DVI connector, use a mini DisplayPort to DVI-D
adapter (active
*
) to connect your monitor cable to the mini
DisplayPort connector on your output cable. Connect the other end
of the cable to your monitor.
* Only active adapters (sold separately) are supported. Passive adapters aren’t supported.
HDMI If your monitor has an HDMI connector, use a mini DisplayPort to
HDMI adapter (active
*
) to connect to the mini DisplayPort connector
on your Matrox card. Connect your monitor to the HDMI connector
on your adapter.
Mini DisplayPort to
DisplayPort adapter
Monitor connector
(DisplayPort)
(M9138 shown)
