Matrox QuadHead2Go Series User Manual

33 Matrox QuadHead2Go Series – User Guide
Button Function
1
(Source selection)
Select your input source. The following are possible input sources:
 Video input
 Logo
 Nature background
 Bezel adjustment grid
 Red
 Green
 Blue
 Gray gradient
2
(Layout configuration)
Select your layout. The selected layout is highlighted in the list. The
available layouts depend on your firmware package and can be
modified through Matrox PowerWall or the QuadHead2Go REST
API.
3
(Device information)
Shows the device information such as:
 Output ID (1, 2, 3, or 4).
 Model number.
 IP address.
 MAC address.
 If IP addressing is dynamic (DHCP) or static.
 Active layout.
 Input mode.
 Output mode.
 If bezel management is enabled.
 If HDCP is enabled.
 If there is an input mismatch between the configuration and the
actual signal.
 If there is an output mismatch between the configuration and the
actual display mode.
 If the physical buttons on your device have been disabled.
 Serial number.
 Firmware version.
 FPGA version.
1 and 2
(Re-enable buttons)
If the physical buttons on your device have been disabled, press
and hold buttons 1 and 2 for 20 seconds to re-enable them.
1 and 3
(Device reset)
Press and hold buttons 1 and 3 for five seconds to reset your
device to its factory default settings.
