37 Matrox QuadHead2Go Series – User Guide
QuadHead2Go Q155 unit
QuadHead2Go Q155
Operating systems supported –
Product type
Standalone appliance
Form factor 1 RU, third width
System memory 1 GB
Audio/Video input connectors 1× HDMI
Audio/Video output connectors 4× HDMI Type A (with 16-bit stereo L-PCM audio)
Networking interface
1× 100/1000 Base-T RJ45 Ethernet Port,
auto-speed, half/full duplex
Color sampling and conversion
RGB: 8:8:8 (24-bit)
YUV: 4:4:4, 4:2:2, 4:2:0 (8-bit)
HDCP support 
Command protocols UPnP, HTTPS
Supported maximum input
resolutions
*
(DisplayPort video input)
* Custom resolutions are also supported. Please contact Matrox for more details. We recommend you use certified HDMI cables
that support your maximum resolution.
3840 × 2160 @ 60 Hz, 3840 × 2160 @ 30 Hz,
7680 × 1080 @60Hz, 7680 × 1080 @30Hz,
1920 × 4320 @60Hz, 1920 × 4320 @30Hz
Supported maximum output
resolutions
*
(HDMI video output)
†‡
† When using a display resolution equal to or higher than 1280×720p60, we recommend you use certified HDMI cables that
support your maximum resolution.
‡ Unless specified, modes are p60 (progressive 60 Hz).
1920 × 1080 @60Hz, 1920 × 1080 @30Hz,
1920 × 1200 @60Hz, 1920 × 1200 @30Hz
Power connector
§
§ Only use the power supply originally supplied by Matrox with your Matrox QuadHead2Go product.
DIN 4 female (4-pin)
Power consumption 24W
Dimensions
13.97 cm × 3.18 cm × 18.11 cm /
5.50 inches × 1.25 inches × 7.13 inches
Regulatory compliance Class A: RCM, CE, FCC, KC
