P/N 03521015 Rev K Page 15
3.4.1 Filter Cover Cap (FCC), 2061-03
The current version FCC includes a right-side and a left-side snap on the rear half of the FCC Skirt (A). These snaps are to
secure the top of the DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM and 2261-01ML/SM, respectively.
The earlier version of FCC does not include these snaps (B) and must not be used with the DLC-Shroud and DLC-Double
Shroud, 2260-05ML/SM and 2261-01ML/SM, respectively.
When upgrading older DLC CAPR Systems to use them with the DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM and
2261-01ML/SM, respectively, you must upgrade those systems to the new version FCC.
NOTE
The new version FCC was included with your 2074-04 Helmet Kits and 2061-03 FCCs if purchased after September
2012.
WARNING
If you have CAPR Helmets with Filter Cover Caps, 2061-03, with lot numbers with a lower number than 1209007-N,
inspect them for the presence of the rear snaps on each side (A). If they are not there, you must replace those FCCs
with newer versions with the snaps to safely use the DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM and
2261-01ML/SM, respectively, with your CAPR Helmets.
3.4. Applicability of Earlier Version Components and Assemblies
