Choose either 115V or 230V setting on input AC power selector switch.
Wire desired input AC power wire to power terminal. A additional single gang box is provided to
install power outlets if desired. GFCI outlet type is recommended.
Additional single gang box
provided. Wire GFCI outlet
to the input AC wire
BEFORE connecting to
operator power terminal if
power outlets are desired.
LEDs should light up on operator.
Battery power automatically turns ON.
Turn Power
ON
DO NOT
CYCLE
OPERATOR!
Turn ALL Power OFF
Turn OFF AC POWER switch on MAX Toroid box.
Battery power will remain ON.
Press and HOLD Red ON/OFF BATTERY button
on the board until BEEP is heard, release button.
IMPORTANT: This procedure
must be followed whenever
ALL power must be turned
OFF on operator.
1
2
Turn Power ON
Chassis (Green)
Neutral (White)
Line (Black)
Chassis (Green)
Neutral (White)
Line (Black)
Single Phase 115VAC Only
115VAC
Single Phase 230VAC Only
230VAC
Input AC Power Options
Set to 115V
115V
230V
Set to 230V
Power Terminal
IMPORTANT: Make sure there are NO exposed bare
wires at the power terminal connection.
115 OR 230VAC
Power Wire
CAUTION: Make sure circuit
breaker is OFF from incoming
AC input wire BEFORE wiring!
disconn
ect
power before
servicing unit
WARNING
WARNING
HIGH
HIGH
VOLTAGE
VOLTAGE
!
Power
Terminal
AC Power
Gang Box
Input AC Power
Selector Switch
AC
IN
FUSE
7 Amp
POWER
On
Off
www.Max.US.com
MAX Toroid 15 Amp
Select Input
Voltage
115 VAC or
230VAC
115V
MAX
Toroid Box
7 Amp Fuse
CAUTION: If input AC power selector
switch is set for 115V but input power
is actually 230 V, 7 Amp Fuse will blow.
AC
Power
Box
Additional
Box
To
Turn OF
F
ALL PO
WE
R:
1
T
urn
OFF
A
C
P
OW
E
R s
wit
ch
on
M
A
X
T
or
oi
d
box
.
B
atte
r
y
power w
il
l
r
em
ain ON
.
2
Pres
s and
HOLD
R
ed
ON
/
OFF BATTE
R
Y
button
on t
he
boar
d
un
t
i
l
BE
EP is heard
,
r
ele
a
s
e but
t
on.
O
N
OFF
O
N/
O
FF
Ba
t
tery
POWER
EXIT CENTER SAFETY
EXIT
CENTER
SAFETY
1
2
5
UL 325 2018 Standard - MAX 1500 PRO/2200 PRO/F18 PRO Matrix III Instal
