Maximum Controls offers a solar power enclosure to power the control box and solar panel (Sold separately).
Mount solar power enclosure underneath control box. Connect solar adapter cable to MODULE PORT.
DO NOT connect AC power to the toroid box.
LOADBATTERYSOLAR
+
-
+
-
+
-
Solar Regulator Terminal
Solar Enclosure
Panel Specs:
200 watt panel
Output: 36 V (maximum) - Open Circuit
Connect to
POWER/
SOLAR IN
NOTE: Cover solar panel
from sunlight BEFORE
wiring to prevent a shock
from occurring.
Use insulated tools and avoid
placing metal objects near the
batteries.
Pos + Red
Neg - Black
Polarity Matters!
Solar
Adapter
cable
Properly Ground Enclosure.
24 V Batteries
Use AGM battery type.
12 Volt
Batteries wired in series
12 Volt
Batteries should be in a
well ventilated enclosure
or overheating will occur
and reduce battery life.
DANGER
HAZARDOUS CURRENT
NEVER touch
positive and
negative battery
cables together!
35 Amp/Hr batteries
Solar Panel
Regulator Specs:
24 V MAX - 20 Amp
J
OG GATE
OPEN / CLOSE
RESET AL
AR
M
Control Box
Solar Enclosure
L
E
LEF
QUICK
L
E
PEN
FF
N
ATE
PEN
M
FF
TI
N
NTR
M
T
P
ITI
NPUT
LIDER
L
SWING
SOLAR MODE
OFF ON
Use flexible conduit to connect
solar enclosure to control box,
not provided.
Turn SOLAR MODE ON.
Mount solar enclosure as close as possible to
control box using 4 existing mounting holes.
7.5”
16.5”
9.5”
1 1/2”
2 3/4”
1 1/2”
2 3/4”
6”
11”
4 Mounting Holes
Mounting hardware
not provided
Back of Solar Enclosure
optional solar power
29
