MAXA 2600 W - Wiring Connections

33
Wiring connections
Connect the cable to the indoor unit
1. Indoor/Outdoor connection cable should be suitable.
2. Lift the indoor unit panel up and remove the screw, then remove the window cover.
3. Connect cables according to their marks to terminals.
4. Wrap those cables not connected with terminals with insulation tapes, so that they will not touch
any electrical components.
Connect the cable to the outdoor unit
1. Remove the electric parts cover from the outdoor unit.
2. Connect the connective cables to the terminals as identified with their respective matched num
bers on the terminal block of indoor and outdoor units.
3. To prevent the ingress of water, from a loop of the connective cable as illustrated in the installation
diagram of indoor and outdoor units.
4. Insulate unused cords (conductors) with PVC-tape. Process them so they do not touch any electri
cal or metal parts.
Wires specifications
8. INSTALLATION
INDOOR UNIT
OUTDOOR UNIT
Front panel Terminal
Acces door
terminal
ON/OFF MONO
Capacity (W)
Power connecting cable Indoor - outdoor connecting cable Main power
supply
Section Section
2600 W, 3500 W 1,5 mm² x 3 1,5 mm² x 5
To indoor unit
5300 W 2,5 mm² x 3 2,5 mm² x 3 + 1,5 mm² x 2 To indoor unit
7000 W 2,5 mm² x 3 2,5mm² x 3 + 1,5 mm² x 3 To indoor unit
YEGN
YEGN
BU BK VT OG
BU BK VT OG
N(1) 2 4 5
N(1)
2 4 5
YEGN
YEGN
BU BK BN VT
OG
BU BK BN VT
OG
N(1) 2 3 4 5
N(1) 2 3 4 5
BU BK BN VT OG
BU BK BN VT OG
YEGN
YEGN
YEGN
N(1) 2 3 4 5
A UNIT: B UNIT:
N(1)
2 3 4
5
L
N
BU BK BN VT OG
N(1)
2 3 4
5
BU BK BN VT OG
YEGN
N(1) 2 3 4 5
N(1)
2 3
N(1)
2 3
BU
BK BN
BNBKBU YEGN
YEGN
ON/OFF MONO: 2600 W, 3500 W, 5300 W ON/OFF DUAL: (2 X 2600 W), (2600 W + 3500 W), (2 X 3500 W)
ON/OFF DUAL
Capacity (W)
Power connecting cable Indoor - outdoor connecting cable Main power
supply
Section Section
2600 W, 3500 W 1,5 mm² x 3 1,5 mm² x 6
To outdoor unit
DC INVERTER MONO
Capacity (W)
Power connecting cable Indoor - outdoor connecting cable Main power
supply
Section Section
2600 W 1,5 mm² x 3 1,5 mm² x 4
To indoor unit
3500 W ~ 7000 W 2,5 mm² x 3 2,5 mm² x 4 To indoor unit
ON/OFF MONO: 7000 W DC INVERTER MONO: 2600 W, 3500 W, 5300 W, 7000 W
