2. PARTS NAMES
2.1. Indoor unit
1
7
8
9
2
3
4
5
6
CA
N
C
E
L
LO
C
K
S
E
T
T
E
M
P
ERA
T
U
R
E
(
°
C
)
A
U
TO
CO
O
L
D
R
Y
HE
A
T
F
AN
HI
G
H
M
E
D
LO
W
TE
M
P
M
O
D
E
S
W
I
N
G
T
I
M
E
R
R
E
S
E
T
O
N/
O
F
F
F
A
N
SP
E
E
D
V
E
N
T
E
C
O
NOM
I
C
RUNN
ING
Component
Name
①
Air inlet
②
Front panel
③
Display
④
Air outlet
⑤
Horizontal air deflector
⑥
Remote controller
⑦
Water inlet pipe
⑧
Water return pipe
⑨
Drain pipe
2.2. Display LCD
Infrared signal receiver
Temperature indicator
Timer indicator
Operation lamp
3. OPERATING RANGE
Maximum operating pressure
1.6Mpa
Minimum operating pressure
0.15MPa
Relative humidity
< 90% (normal 0 ~ 80%)
Minimum inlet water temperature for cooling
3°C
Maximum inlet water temperature for heating
70°C (normal 50°C)
The pH of water
6.5~7.5.
Cooling / Heating
Outdoor temperature
21°C ~ 43°C / -5°C ~ 24°C
Room temperature
17°C ~ 32°C / 0°C~ 30°C
Water inlet temperature
3°C~ 20°C / 30°C ~ 70°C
