SPECIFICATION/COMPONENT IDENTIFICATION
2-2
2.1 TECHNICAL SPECIFICATION
Model Metric US 20 lbs. 30 lbs. 40 lbs. 60 lbs. 80 lbs. 100 lbs.
Maximum capacity: kg. lbs. 9 (20) 13.6 (30) 18.1 (40) 27.2 (60) 36.3 (80) 45.3 (100)
OVERALL DIMENSIONS:
A – Machine Width mm. inch 663 (26.1”) 735 (28.9”) 785 (30.9”) 880 (34.6”) 1050 (41.3”) 1050 (41.3”)
B – Machine Depth mm. inch 795 (31.3”) 885 (34.8”) 1090 (42.9”) 1177 (46.3”) 1219 (48”) 1374 (54.1”)
C – Machine Height mm. inch 1201 (47.3”) 1270 (50”) 1320 (52”) 1467 (57.8”) 1708 (67.2”) 1722 (67.8”)
CYLINDER INFORMATION:
Basket Diameter mm. inch 610 (24”) 610 (24”) 680 (26.8”) 790 (31.1”) 920 (36.2”) 920 (36.2”)
Basket Depth mm. inch 345 (13.5”) 470 (18.5”) 525 (20.7”) 595 (23.4”) 574 (22.6”) 718 (28.3”)
Basket Volume cu.m cu.ft 0.11 (4) 0.14 (5) 0.19 (7) 0.29 (10) 0.4 (13) 0.5 (17)
DOOR OPENING AND HEIGHT:
Door Opening Diameter mm. inch 365 (14.4”) 365 (14.4”) 365 (14.4”) 450 (17.7”) 510 (20.1”) 510 (20.1”)
Height Of Door Bottom Above Floor mm. inch 387 (15.2”) 445 (17.5”) 465 (18.3”) 540 (21.3”) 610 (24”) 627 (24.7”)
DRIVE INFORMATION:
Number of Motors Number 1 1 1 1 1 1
Size of Motor kW HP 0.75 (1) 1.5 (2) 2.2 (3) 3.7 (5) 5.5 (7.5) 7.5 (10)
CYLINDER SPEEDS (PROGRAMMABLE):
Wash RPM G-Force 48.5 (0.8) 48.5 (0.8) 44.4 (0.8) 43 (0.8) 39.5 (0.8) 39.5 (0.8)
Distribution RPM G-Force 76.5 (2) 77 (2) 70.2 (2) 67 (2) 62 (2) 62 (2)
Extract RPM G-Force 484 (80) 664 (150) 608 (150) 583 (150) 540 (150) 540 (150)
WATER INLETS AND CONSUMPTION:
Hot water size
NPT
3/4” 3/4” 3/4” 3/4” 3/4” 1”
Cold water size 3/4” 3/4” 3/4” 3/4” 3/4” 1”
Additional water Inlet 3/4” 3/4” 3/4” 3/4” 3/4” 1”
Average HOT water consumption/cycle Liters Gal 22 (6) 22 (6) 23 (6) 46 (12) 48 (13) 58 (15)
Average COLD water consumption/cycle Liters Gal 67 (18) 67 (18) 69 (18) 104 (27) 137 (36) 168 (44)
DRAIN OUTLETS AND CAPACITY:
Number of drains Number 1 1 1 1 1 1
Drain size mm inch 50.8 (2”) 50.8 (2”) 50.8 (2”) 76.2 (3”) 76.2 (3”) 76.2 (3”)
Drain capacity liters/min gpm 117 (31) 117 (31) 310 (81.9) 581 (153.5) 581 (153.5) 581 (153.5)
STEAM INLETS AND CONSUMPTION:
Steam Inlet Size NPT 1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
Steam Pressure bar psi 6 (100) 6 (100) 6 (100) 6 (100) 6 (100) 6 (100)
Steam Consumption kg/hr lb/hr 11 (24.15) 11 (24.15) 23.5 (51.75) 34.4 (75.9) 56.3 (124.2) 56.3 (124.2)
WEIGHT AND SHIPPING INFORMATION:
Net Weight kg. lbs. 240 (530) 286 (630.5) 437 (963.4) 499 (1100) 740 (1631) 875 (1930)
Domestic shipping weight kg. lbs. 286 (630.5) 302 (665.8) 455 (1003) 519 (1144) 767 (1691) 895(1973)
