Maxi MWHE20 - Cycle Execution; Display Indications

OPERATING INSTRUCTIONS
4-2
CYCLE EXECUTION
A cycle can be aborted at any time by pressing the stop key. The machine will enter the stop
routine after witch the door may be unlocked (display reads donE).
To display the temperature of the wash solution during a cycle, press the up key. To display
the cycle number currently in process, press the start key. To display segment name currently in
process, press the down key.
DISPLAY INDICATIONS
The following table lists the displays the WE 01/WE 05 putter is capable of and their
meanings. Familiarize yourself with these displays and their meanings.
Display
Meaning
Display
Meaning
504
Rom code. Example only
cFlL
Cold Fill
hold
Wait – machine just powered up
bFlL
Warm Fill (both hot and cold)
cy
Cycle number (followed by 2 digits)
hFlL
Hot Fill
chEc / cYc
Test Cycle
LoLE
Low water level
FRr
Degrees Fahrenheit
MdL
Medium water level
cEL
Degrees Celsius
hlLE
High water level
PrE
Prewash segment (1
st
of 8 segments)
SUP 1
Supply 1
URSh
Wash segment (2
nd
of 8 segments)
SUP 2
Supply 2
FlL 1
First rinse (3
rd
of 8 segments)
SUP 3
Supply 3
FlL 2
Second Rinse (4
th
of 8 segments)
SUP 4
Supply 4
FlL 3
Third Rinse (5
th
of 8 segments)
SUP 5
Supply 5 (Supply 1 & 2)
FlL 4
Fourth Rinse (6
th
of 8 segments)
SUP 6
Supply 6 (Supply 2 & 3)
FlL 5
Fifth Rinse (7
th
of 8 segments)
SUP 7
Supply 7 (Supply 3 & 4)
FlL 6
Sixth Rinse (8
th
of 8 segments)
StoP
Stop Routine
Sr ln
Spray Rinse
SdLy
Spin coast down delay
Dr ln
Dilution Rinse
donE
Cycle complete, open the door
PrEu
Normal Prewash selected
door
Door not closed and locked
SP ln / lnE
Reads “spin” for one second, then
“time” followed by the spin time
FlLL /
StoP
Programmed water level not reached
after 30 minutes
tSFL
Temperature sensor failure or
temperature out of range.
FULL
Water level is detected when none
should be present. Can indicate a
clogged drain.
FLUS
Overflow prewash selected
Each of the 30 cycles consists of 8 segments. A typical cycle has Pre wash, Wash, and
Rinses (up to six are available. Upon the completion of the last rinse, a final spin occurs. Following
is a description of each cycle segment.
FILL
After the start key is pressed, the drain is closed and the machine begins filling to the
appropriate water level. Each wash segment begins with a fill. After the water level is reached, the
cycle time begins to count down (the cycle timer is paused during fill, heat and drain steps). If a
supply is programmed during the segment, the dispenser will be flushed during the fill.
If the machine is connected to an external chemical supply system, the programmed supply
will begin 10 seconds into the programmed water level is reached, or sixty seconds have elapsed. If
the water level is not reached after 30 minutes, the display will flash Stop and Fill The onboard
beeper will also sound for 10 seconds. The machine will then enter the stop routine.
