OPERATING INSTRUCTIONS
4-3
WASH
Standard Wash
As soon as the programmed water level is reached (and any programmed temperature is
reached) the display begins to count down the remaining time left in the cycle.
All except three cycles use the standard agitation profile. This agitation profile is active
during prewash, wash, and rinses. The standard sequence is:
12 seconds counterclockwise at wash speed
3 second pause
12 seconds clockwise at wash speed
3 second pause
Gentle Wash
Cycles 8, 16, and 24 use a gentle agitation profile. This profile is used in the prewash, wash,
and rinse steps. The gentle wash agitation profile is:
Heat
If a wash segment contains a heat step, the heating elements will begin to heat the wash
solution after the programmed level has been reached. If the water does not reach the desired
temperature after 30 minutes, the machine will progress to the next step.
SELECTION ADVANCE
Advance Mode
While any cycle is running, operator can end the current step and advance to the next one by
pressing the up and down key together. This mode use for skip currently to next step in segment.
NOTE: During fill water, drain step of each segment the advance function can not
execute.
NOTE: Water level to be reached before advance is possible
- Fill (Heater start) to wash
- Wash to drain
- Spin to stop routine segment
Press together for advance step in this program.
3 seconds counterclockwise at wash speed
12 second pause
3 seconds clockwise at wash speed
12 second pause
DRAIN
At the conclusion of a prewash, wash, or rinse segment, the drain valve opens and the wash
cylinder turns clockwise at wash speed. The machine should drain in less than 30 seconds. If
draining takes longer than this, a clogged drain hose is usually to blame. Contact a qualified service
technician.
