Maxi MWHE20 - Page 70

20 lb. 30 lb. 40 lb. 60 lb. 80 lb.
1
A1-ST00-002 A1-ST00-002 A1-ST00-002 A1-ST00-002 A1-ST00-002
1 Set
Door lock assembly complete set
2
A0-A237-001 A0-A237-001 A0-A237-001 A0-A237-001 A0-A237-001 1 Door lock cover Plastic
A0-A001-079 ----1Gasket Door, Silicone L=990mm.
A0-A001-011 A0-A001-011 - - 1
Door Gasket Silicone Orange, Length 44.1"
- - - A0-A001-012 - 1 Door Gasket Silicone Orange, Length 54"
----A0-A001-014 1
Door Gasket Silicone Orange, Length 60.6"
A1-S204-010 ----1Basket stainless steel
- A1-S302-018 - - - 1 Basket stainless steel
- - A1-S402-018 - - 1 Basket stainless steel
- - - A1-S602-018 - 1 Basket stainless steel
----A1-S802-018 1 Basket stainless steel
A0-A005-104 A0-A005-104 - - - 1 Seal, V-Ring (STD)
- - A0-A005-105 A0-A005-105 - 1 Seal, V-Ring (STD)
- - A0-A005-337 - - 1 Seal, V-Ring (Option)
5
A0-A013-009 A0-A013-009 A0-A013-009 A0-A013-009 A0-A013-009 1 Door lock block
6
A0-A036-001 A0-A036-001 A0-A036-001 A0-A036-001 A0-A036-001 1
Magnet actuator for magnetic reed Switch (White)
7
A0-A008-120 A0-A008-120 A0-A008-120 A0-A008-120 A0-A008-120 1 Spring, Solenoid lock
8
A0-E015-018 A0-E015-018 A0-E015-018 A0-E015-018 A0-E015-018 1
Solenoid Door Lock Magnetic , Latching 1 Coil 24VDC. + Pin
9
A0-E014-015 A0-E014-015 A0-E014-015 A0-E014-015 A0-E014-015 2 Micro switch
10
A0-E014-007 A0-E014-007 A0-E014-007 A0-E014-007 A0-E014-007 1 Switch, Magnet reed
11
A1-ST00-002-01 A1-ST00-002-01 A1-ST00-002-01 A1-ST00-002-01 A1-ST00-002-01
1 Base box with Guides
Qty. Description
Section 8
4
Part List : Door Lock Assembl
