Maxi MWHE20 - Page 82

20 lb. 30 lb. 40 lb. 60 lb. 80 lb.
A0-M008-068 A0-M008-068 - - - 1 Motor pulley
- - A0-M009-084 A0-M009-084 - 1 Motor pulley
----A0-M008-123 1 Motor pulley
A0-M009-076 A0-M009-076 - - - 1 Motor pulley bushing
- - A0-M009-191 A0-M009-191 - 1 Motor pulley bushing
A0-M009-091 1 Motor pulley bushing
A0-A079-036 A0-A079-036 - - A0-A079-036 3 Hex. bolt
A0-M008-214 ----1Basket Pulley
- A0-M008-067 - - - 1 Basket pulley
- - A0-M008-117 A0-M008-117 - 1 Basket pulley
----A0-M008-120 1 Basket pulley
A0-M008-172 A0-M008-172 - - - 1 Basket pulley bushing
- - A0-M009-080 A0-M009-080 - 1 Basket pulley bushing
----A0-M008-173 1 Basket Pulley Bushing
A0-A002-984 ----1V-Belt
- A0-A002-172 - - - 1 V- Belt
- - A0-A002-171 - - 2 V- Belt
- - - A0-A002-169 - 2 V- Belt
----A0-A002-173 2 V- Belt
A0-A018-080 A0-A018-080 A0-A018-080 - - 1 Overflow Hose
- - - A0-A018-079 - 1 Overflow Hose
----A0-A018-077 1 Overflow Hose
A0-A018-072 ----1Drain Hose
- A0-A018-069 - - - 1 Fill Hose
A0-A018-082 - - 1 Fill Hose
A0-A018-068 A0-A018-068 1 Fill Hose
A0-A074-703 A0-A074-703 - - - 8 Hex. Bolt
- - A0-A074-852 A0-A074-852 A0-A074-852 8 Hex. Bolt
8
A0-A008-175 A0-A008-175 A0-A008-175 A0-A008-175 - 1 Spring tension
A1-S202-041 ----1Tension spring mounting plate
- A1-S302-041 - - - 1 Tension spring mounting plate
- - A1-S402-041 - - 1 Tension spring mounting plate
- - - A1-S602-041 - 1 Tension spring mounting plate
A0-E041-004 A0-E041-004 A0-E041-004 - - 1 Drain valve assembly
- - - A0-E041-002 A0-E041-002 1 Drain valve assembly
11
A0-A237-005 A0-A237-005 A0-A237-005 A0-A237-005 A0-A237-005 1 Set
Cover Box + Mounting Box Drain Valve, Plastic Complete Set
12
A0-A237-005-02 A0-A237-005-02 A0-A237-005-02 A0-A237-005-02 A0-A237-005-02
1 Cover Box Drain Valve, Plastic
13
A0-A237-005-01 A0-A237-005-01 A0-A237-005-01 A0-A237-005-01 A0-A237-005-01
1 Mounting Box Drain Valve, Plastic
A0-A007-045 ----1Housing
- A0-A007-016 - - - 1 Housing bearing
- - A0-A007-043 A0-A007-043 - 1 Housing bearing
----A0-A007-012 1 Housing bearing
A1-S204-024 ----1Motor support
- A1-S302-045 - - - 1 Motor support
- - A1-SHE2-022 A1-SHE2-022 - 1 Motor support
----A1-S802-045 1 Motor support
A1-S204-016 ----1Main frame
- A1-S302-044 - - - 1 Main frame
- - A1-S402-044 - - 1 Main frame
- - - A1-S602-044 - 1 Main frame
----A1-S802-044 1 Main frame
17
- - A0-A106-004 - - 1
Tailpiece Brass 1/2" (Option)
18
- - A0-A020-017 - - 1
Ball Valve Sus 1/2" (Option)
19
- - A0-A018-016 - - 1
Hose, Water Supply Flush Hose, 1/2"(Option)
20
- - A0-A052-056 - - 2
U-Bolt 1/2" (Option)
14
15
16
Item
Part No.
Qty. Description
2
3
4
5
6
9
7
10
