XStream™OEMRFModule–ProductManualv5.x00[2006.02.24]
3.2. Command Reference Table
Table3‐01. XStreamCommands(Themoduleexpectsnumericalvaluesinhexadecimal.“d”denotesdecimalequivalent.)
AT
Command
Binary
Command
AT Command Name Range Command Category
# Bytes
Returned
Factory
Default
AM v4.30* 0x3A (58d) Auto-set MY - Networking & Security - -
AT 0x05 (5d) Guard Time After 0x02 – 0xFFFF [x 100 msec] Command Mode Options 2 0x0A (10d)
BD v4.2B* 0x15 (21d) Baud Rate
Standard baud rates: 0 – 6
(custom rates also supported)
Serial Interfacing 2
factory-set
RF data rate
BK v4.30* 0x2E (46d) Serial Break Passing 0 – 1 Serial Interfacing 1 0
BO v4.30* 0x30 (48d) Serial Break Timeout 0 - 0xFFFF [x 1 second] Serial Interfacing 2 0
BT 0x04 (4d) Guard Time Before 0 – 0xFFFF [x 100 msec] Command Mode Options 2 0x0A (10d)
CB v4.30* 0x33 (51d) Connection Duration Timeout 0x01 – 0xFFFF [x 100 msec] Networking & Security 2 0x28 (4d sec)
CC 0x13 (19d) Command Sequence Character 0x20 – 0x7F Command Mode Options 1 0x2B (“+”)
CD v4.2B* 0x28 (40d) DO3 Configuration 0 – 4 Serial Interfacing 1 0
CE v4.30* 0x34 (52d) Connection Inactivity Timeout 0 – 0xFFFF [x 10 msec] Networking & Security 2 0x64 (1d sec)
CF v4.30* 0x35 (53d) Connection Failure Count 0 – 0xFFFF Networking & Security 2 0
CL v4.30* 0x39 (57d) Last Connection Address [read-only] Diagnostics 2 -
CM v4.30* 0x38 (56d) Connection Message 0 – 1 Networking & Security 1 0
CN 0x09 (9d) Exit AT Command Mode - Command Mode Options - -
CO v4.30* 0x2F (47d) DO3 Timeout 0 - 0xFFFF [x 1 second] Serial Interfacing 2 0x03
CS v4.27D* 0x1F (31d) DO2 Configuration 0 – 4 Serial Interfacing 1 0
CT 0x06 (6d) Command Mode Timeout 0x02 – 0xFFFF [x 100 msec] Command Mode Options 2 0xC8 (200d)
DC v4.30* 0x37 (55d) Disconnect - Networking & Security - -
DR v4.30* 0x2D (45d) DI3 Configuration 0 – 4 Serial Interfacing 1 0
DT 0x00 (0d) Destination Address 0 – 0xFFFF Networking & Security 2 0
E0 0x0A (10d) Echo Off - Command Mode Options - -
E1 0x0B (11d) Echo On - Command Mode Options - -
ER 0x0F (15d) Receive Error Count 0 – 0xFFFF Diagnostics 2 0
FH 0x0D (13d) Force Wake-up Initializer - Sleep (Low Power) - -
FL 0x07 (7d) Software Flow Control 0 – 1 Serial Interfacing 1 0
FT v4.27B* 0x24 (36d) Flow Control Threshold 0 – 0xFF [bytes] Serial Interfacing 2 varies
GD 0x10 (16d) Receive Good Count 0 – 0xFFFF Diagnostics 2 0
HP 0x11 (17d) Hopping Channel 0 – 6 Networking & Security 1 0
HT 0x03 (3d) Time before Wake-up Initializer 0 – 0xFFFF [x 100 msec] Sleep (Low Power) 2 0xFFFF
ID v4.2B* 0x27 (39d) Modem VID
User-settable: 0x10 - 0x7FFF
Read-only: 0x8000 – 0xFFFF
Networking & Security 2 -
IU v4.30* 0x3B (59d) DI2, DI3 Update Timer 0 - 0xFFFF [x 100 msec] Serial Interfacing 2 0x0A (10d)
LH 0x0C (12d) Wake-up Initializer Timer 0 – 0xFF [x 100 msec] Sleep (Low Power) 1 0x01
MD v4.30* 0x32 (50d) RF Mode 0 – 4 Networking & Security 1 0
MK 0x12 (18d) Address Mask 0 – 0xFFFF Networking & Security 2 0xFFFF
MY v4.30* 0x2A (42d) Source Address 0 – 0xFFFF Networking & Security 2 0xFFFF
NB v4.30* 0x23 (35d) Parity 0 – 5 Serial Interfacing 1 0
PC v4.22* 0x1E (30d) Power-up Mode 0 – 1 Command Mode Options 1 0
PK v4.30* 0x29 (41d) RF Packet Size 0 - 0x100 [bytes] Serial Interfacing 2 0x40 (64d)
PW v4.22* 0x1D (29d) Pin Wake-up 0 – 1 Sleep (Low Power) 1 0
RB v4.30* 0x20 (32d) Packetization Threshold 0 - 0x100 [bytes] Serial Interfacing 2 0x01
RE 0x0E (14d) Restore Defaults - (Special) - -
RN v4.22* 0x19 (25d) Delay Slots 0 – 0xFF [slots] Networking & Security 1 0
RO v4.2A* 0x21 (33d) Packetization Timeout 0 – 0xFFFF [x 200 µsec] Serial Interfacing 2 0
RP v4.2A* 0x22 (34d) RSSI PWM Timer 0 - 0x7F [x 100 msec] Diagnostics 1 0
RR v4.22* 0x18 (24d) Retries 0 – 0xFF Networking & Security 1 0
RS v4.22* 0x1C (28d) RSSI 0x06 – 0x36 [read-only] Diagnostics 1 -
RT 0x16 (22d) DI2 Configuration 0 - 2 Serial Interfacing 1 0
RZ v4.30* 0x2C (44d) DI Buffer Size [read-only] Diagnostics - -
SB v4.2B* 0x36 (54d) Stop Bits 0 - 1 Serial Interfacing 1 0
SH v4.27C* 0x25 (37d) Serial Number High 0 – 0xFFFF [read-only] Diagnostics 2 -
SL v4.27C* 0x26 (38d) Serial Number Low 0 – 0xFFFF [read-only] Diagnostics 2 -
SM 0x01 (1d) Sleep Mode 0 – 8 Sleep (Low Power) 1 0
ST 0x02 (2d) Time before Sleep 0x10 – 0xFFFF [x 100 msec] Sleep (Low Power) 2 0x64 (100d)
SY 0x17 (23d) Time before Initialization 0 – 0xFF [x 100 msec] Networking & Security 1 0 (disabled)
TO v4.30* 0x31 (49d) DO2 Timeout 0 - 0xFFFF (x 1 sec) Serial Interfacing 2 0x03
TR v4.22* 0x1B (27d) Transmit Error Count 0 – 0xFFFF Diagnostics 2 0
TT v4.22* 0x1A (26d) Streaming Limit 0 – 0xFFFF [0 = disabled] Networking & Security 2 0xFFFF
VR 0x14 (20d) Firmware Version 0 x 0xFFFF [read-only] Diagnostics 2 -
WR 0x08 (8d) Write - (Special) - -
NOTE:ATCommandsissuedwithouta
parametervaluewillreturnthecurrently
storedparameter.
*Firmwareversioninwhichcommandandparameteroptionswerefirstsupported.
©2006MaxStream,Inc.ConfidentialandProprietary 19
